Virtual Collimator Mobile C Arm X Ray Machine

Mobile DSA System

Send Inquiry

Product Introduction

Description Of Virtual Collimator Mobile C Arm X Ray Machine:

Alien E mobile X-ray C arm interventional treatment is imported Italian mobile X-ray medical equipment, the product design is used for the diagnosis, surgical and interventional treatment process to provide insight and digital images. Its clinical applications include orthopedics, neurology, vascular surgery, cardiology, critical care, and emergency operation

Index Of Virtual Collimator Mobile C Arm X Ray Machine:

High-voltage Generator

Maximum voltage: 20kW
Inverter frequency: 40kHz
HCF voltage range: 40 kV – 120 kV,1kV step
CINE voltage range: 40 kV – 125 kV, 1kV step
RAD voltage range: 40 kV – 125 kV, 1kV step
HCF current range: 10 mA – 63 mA 1, 10 mA step
CINE current range: 40 mA – 200 mA 1, 20 mA step
RAD current range: 40 mA – 200 mA , 20 mA step

X-ray Tube

Tube type: Dual focus, rotating anode, water cooling
Dual focus, big focus 0.6mm, small focus 0.3mm
Nominal power, small focal: 8.3kW
Nominal power, large focal: 22.5 kW

Collimator

Control method: All-electric control
Blade window size: 0- 75 mm×75 mm continuous adjustable
Windows shape: windows opening size automatic tracking with the SID (intelligent tracking)
Iris: lead blades iris for total filtration

Dynamic FPD

Detector type: A-Si dynamic flat panel detector
Nominal area: 30cm×30cm
A/D range: 16 bit
Pixel pitch:194 µm
DQE: 77%

Grid

Removable grid
Ratio: 10:1
Density: 60L/cm

C-arm gantry

Control method: All-electric control, isocentric
C-arm lift: 500mm
C-arm depth: 750mm
C-arm opening: 960mm
SID: 1050-1180mm
Horizontal movement: 220mm
WIG-WAG: 22°
C-arm rotation: ±200°
LAO/RAO: 200°/200°, error ±3°
C-arm sliding: 138°
CRA/CAU: 90°/45°, error ±3°

Control device

Hand switch: Two steps hand switch
Foot switch: Dual pedal
Console box: several joysticks

Image acquisition & processing system

Real-time fluoroscopy function
Have subtraction angiography image peak value holding function
Radiography acquisition function, the highest rate is 25 fps.
Has the option to show the image ratio and window adjustment
With manual frame by frame playback, loop playback, playback rate for collecting rate of 10% ～200% is adjustable
With functions of real-time digital subtraction angiography
Fluoroscopy dynamic storage function
Has the image 90 degrees, 180 degrees, 270 degrees and the function of image

Print & Storage

Display digital image library storage condition, memory: 300000 images
USB port and storage are available, which can be saved in a variety of common formats such as DCM/JPG/AVI, without conversion or special browsing software
DICOM3.0 (PRINT, STORAGE, WORKLIST, MPPS)
