150KJ Anode Heat Capacity C-arm X Ray Machine

Product video:

Product Features:

• Dual medical monitor

• Intelligent control center

• Dynamic flat panel detector

• Large C arm opening size

• Large heat capacity rotating anode tube

• 5kW high-voltage generator

Product Parameters:

X-ray generator

• Input power voltage: 220VAC±10%

• High-frequency inverter frequency:40kHz

• Output power:5kW (100kV、50mA、0.1s)

• Tube current: 0.2-100mA

• Radiography tube voltage: 40-120KV

• Small focus 0.3mm, large focus0.6mm

Collimator

• Additional filters: Air; 1mmAl+0.1mmCu; 1mmAl+0.2mmCu; 2mmAl

• 0-35cm×35cm@100cm SID continuous adjustable of X-ray filed size

• Advanced technology: Liquid metal bearing technology

Dynamic FPD

• Amorphous silicon Csi

• FPD size: 21cmx21cm

• 1024×1024 matrix

C arm Movement

• Lateral movement:250mm

• Vertical lifting movement:450mm

• Swing left & right: 25°

• C-arm orbital range: 135°

• Rotate around the horizontal axis: ±225°

• C-arm depth:780mm

• C-arm opening: 820mm

• SID:1050m

Image Acquisition & Processing

• Workstation: 1*PC, CPU2.8GHz, 8GB memory, 1T hard disk，120GSSD, 2 *USB2.0 interface

• two 19’ touch-screen medical monitors on trolley; 1* 13.3’ touch-screen monitor on C-arm gantry

• Monitor resolution of C-arm gantry: 1920*1080

Post-processing

• Window width/level adjustment

• Recursive noise reduction

• Imaging zoom

• Magnifier

• Image rotation

• Horizontal image

• Vertical image

• Annotation, including polygon, circle, rectangle, line, arrow and test.

• Line segment and angle measurement function.
